Trek Emonda ALR Frameset, Rim Brake, Aluminum w/ Carbon Fork, H2 Geo,

Emonda ALR Frameset

The Emonda ALR Frameset delivers the look and performance of a carbon road bike at a much friendlier alloy price point. With shaped tubes and Invisible Weld Technology, this aluminum frame is the ideal foundation for building a high-performance, high-value road machine.

Is this the right frame for you?

• You want a race-worthy alloy frame that rivals carbon in appearance and handling.
• You're building a road bike for club rides, competitive events, or spirited training.

Tech Highlights

• 300 Series Alpha Aluminum frame with shaped tubing
• Invisible Weld Technology for clean, seamless joints
• Émonda SL full carbon fork with tapered steerer
• Internal cable routing for a clean look and longer cable life
• Built for direct mount rim brakes
• H2 geometry for balanced performance and comfort

Why You'll Love It

• It climbs fast, corners hard, and descends with confidence
• H2 geometry offers a ride quality that rivals far more expensive carbon frames
• Internal cable routing enhances aesthetics and durability
• Like all Émondas, it’s backed by a lifetime warranty

Technical Specifications

• Frame: 300 Series Alpha Aluminum, Invisible Weld, Control Freak internal routing, direct mount rim brakes, 130x5mm QR, PressFit 86.5mm BB
• Fork: Emonda SL full carbon, tapered steerer, carbon dropouts, 5x100mm QR
• Frame Fit: H2
• Headset: FSA Integrated, sealed cartridge, 1-1/8" top, 1.5" bottom
• Max Tire Size: 26mm
• Weight (56cm): 1.75 kg / 3.85 lbs
• Weight Limit: 275 lbs (125 kg) total system weight

Sizing Guide Size Rider Height Inseam 47 152 - 158 cm (5'0" - 5'2") 71 - 75 cm (28" - 30") 50 158 - 163 cm (5'2" - 5'4") 74 - 77 cm (29" - 30") 52 163 - 168 cm (5'4" - 5'6") 76 - 79 cm (30" - 31") 54 168 - 174 cm (5'6" - 5'9") 78 - 82 cm (31" - 32") 56 174 - 180 cm (5'9" - 5'11") 81 - 85 cm (32" - 33") 58 180 - 185 cm (5'11" - 6'1") 84 - 87 cm (33" - 34") 60 185 - 190 cm (6'1" - 6'3") 86 - 90 cm (34" - 35") 62 190 - 195 cm (6'3" - 6'5") 89 - 92 cm (35" - 36") 64 195 - 200 cm (6'5" - 6'7") 91 - 94 cm (36" - 37")
